Mating Cycle：≥5,000 Cycles | Voltage Rating：72V DC | Operating Temperature：-40°C to 105°C |
Pullout Force：<100N | Current Rating：40A + 5A | IP Rating：IP67 Battery Side |
Wire Processing：Crimp | Withstand Voltage：1,500V AC | Salt Spray：5% Nacl, 48H |
Wire Gauge：Power 8AWG/ Max Signal 20AWG/ Max | Insulation Resistance：>200MΩ at DC 500V | Flammability Rating：UL94V-0 |
